Hydraulic Impact Shear

The hydraulic impact shear cuts the material during continuous operation using two shear bushings.

The electric servo drive enables precise speed control of the shear carriage. The high cutting speed and the fine adjustment of the shear bushings ensure optimal cutting surfaces. Cutting is also possible in stationary mode. A scrap-length control system can also be used. If shearing cannot be applied (pipes, hollow profiles, etc.), a sawing unit or a chip-free cutting device can be mounted on the base frame instead of the shear head.

🚀 Maximum precision, maximum power – as strong as an elephant! 🐘

The essential machine for the production of high-quality steel – faster, stronger and more reliable:

🔹 Speed: max. 120 m/min

🔹 Cutting capacity: 40 mm (hexagon & round bar)

🔹 Motor: Siemens 1FK8 servo technology

🔹 Gearbox: Neugart

🔹 Linear guide: THK (45 series)

🔹 Rack: Güdel

🔹 Hydraulic power unit: Bosch Rexroth – hoses with clamp protection

🔹 Pressure sensor: Balluff

🔹 Automation: Siemens S7-1500TF

🔹 Safety: Pilz safety components

🔹 HMI Panel: Siemens TP1500

🔹 Encoder: Sick AFM60A

🔹 Climate unit: 2000W electrical cabinet cooling

🔹 Designed for long-term endurance — 30 mm wall thickness and 50 mm main carrier.

Published Date: 17.11.2025
